PM2 Environment Variables: Setup, Update & Best Practices

PM2 environment variables are one of those things that seem simple until they bite you. You set a variable, restart the process, and nothing changes. Or you use the wrong flag and wonder why your app is running on the wrong port. I’ve seen these mistakes trip up experienced developers, and the old PM2 documentation doesn’t help much.

This guide covers the correct way to set, update, and secure environment variables in PM2 (currently at version 7.0.3, requiring Node.js 18+). If you’re looking for a broader overview of process management, check managing applications with PM2 first. For operators running multiple apps on a VPS, the best self-hosted server management panels can help with visibility across your stack.

Setting environment variables via the command line in PM2

The correct way to pass environment variables when starting a PM2 process uses standard Unix environment variable syntax: prefix the command with VAR=value.

# ❌ This is NOT how PM2 env vars work
pm2 start app.js --env PORT=3000
pm2 start app.js --env PORT=3000,DB_URL=mongodb://localhost:27017/mydb

# Single variable:
PORT=3000 pm2 start app.js

# Multiple variables (space-separated):
PORT=3000 DB_URL=mongodb://localhost:27017/mydb SECRET=abc123 pm2 start app.js

Verify it worked:

# Find your process ID first
pm2 list

# Then inspect the environment (replace 0 with your process id)
pm2 env 0

You should see PORT=3000 in the output. If it’s missing, double-check the prepend syntax. The variables must come before pm2 start.

For PM2 cluster mode with multiple instances, you’ll typically want different ports per instance. increment_var handles that automatically (see the advanced section).

Setting environment variables with PM2 ecosystem files

For any production application, the ecosystem file is the right approach. It gives you a single config file that defines your app, its environment variables, and how PM2 should run it.

Basic env, env_production, and env_development blocks

// ecosystem.config.js
module.exports = {
  apps: [
    {
      name: "my-app",
      script: "./app.js",
      // Default env. Used when no --env flag is passed
      env: {
        NODE_ENV: "development",
        PORT: 3000,
        APP_LOG_LEVEL: "debug",
      },
      // Used with: pm2 start ecosystem.config.js --env production
      env_production: {
        NODE_ENV: "production",
        PORT: 3000,
        APP_LOG_LEVEL: "info",
      },
      // Used with: pm2 start ecosystem.config.js --env staging
      env_staging: {
        NODE_ENV: "staging",
        PORT: 3000,
        APP_LOG_LEVEL: "warn",
      },
    },
  ],
};

Each env_* block corresponds to a name you pass with --env. The base env block is the default when no --env flag is used.

Switching environments with –env [name]

# Start with development env (default):
pm2 start ecosystem.config.js

# Start with production env:
pm2 start ecosystem.config.js --env production

# Start with staging env:
pm2 start ecosystem.config.js --env staging

Modern ecosystem file formats and scaffolding

PM2 supports more than just .js files:

• ecosystem.config.js / ecosystem.config.cjs / ecosystem.config.mjs
• ecosystem.json / ecosystem.json5
• ecosystem.yaml / ecosystem.yml

To scaffold a starter config:

pm2 init simple

This creates a basic ecosystem.config.js you can fill in.

Verify:

pm2 start ecosystem.config.js --env production
pm2 env 0   # Confirm NODE_ENV=production appears

If the wrong env block values appear, the --env name doesn’t match your ecosystem file key. --env prod will not match env_production. The name must match exactly.

How to update environment variables for a running PM2 application

This is where most people get stuck. PM2 is conservative by default: environment variables are essentially immutable once a process starts.

The –update-env flag

To change a variable for a CLI-started process:

# Set the new value and restart with --update-env
PORT=4000 pm2 restart my-app --update-env

To confirm the change took effect:

pm2 env 0   # Look for PORT=4000

For ecosystem file changes, just restart with the same --env flag:

# Edit env_production in ecosystem.config.js, then:
pm2 restart ecosystem.config.js --env production

Ecosystem file variables are always updated on restart. You don’t need --update-env for those.

Full delete + restart for stubborn variables

Some variables, most notably NODE_ENV, are read once at startup and won’t change even with --update-env. When that happens, delete and re-add is the only reliable path:

pm2 delete my-app
pm2 start ecosystem.config.js --env production

This is a known behavior. Community reports (GitHub issues #3192, #4135, #5591) confirm that --update-env can be unreliable in certain edge cases. When in doubt, delete and re-add.

The pm2 save / pm2 resurrect footgun

If you use pm2 save to persist your process list for auto-restart on reboot (via pm2 startup), be aware: pm2 save freezes the current environment variables into the dump file. When you later run pm2 resurrect, those saved values are used, even if you’ve changed the ecosystem file.

The fix: after changing env vars, delete and re-add your processes, then save again:

pm2 delete my-app
pm2 start ecosystem.config.js --env production
pm2 save

Advanced PM2 environment variable features

These features matter most when running multiple instances or deploying to multiple environments on the same server.

filter_env: prevent global env var leaks

By default, your PM2 process inherits all environment variables from the parent shell. That includes system vars, vars from other apps, and anything exported in your .bashrc. filter_env lets you whitelist a prefix.

module.exports = {
  apps: [
    {
      name: "my-app",
      script: "./app.js",
      // Only pass env vars that start with APP_ or DB_
      filter_env: ["APP_", "DB_"],
    },
  ],
};

To drop all global env vars entirely:

filter_env: true,

This is a security feature. It prevents accidental leakage of secrets or variables from other processes. See the security section for more.

increment_var: auto-increment PORT per cluster instance

When running in PM2 cluster mode, each instance needs its own port. Instead of hardcoding ports, use increment_var:

module.exports = {
  apps: [
    {
      name: "api",
      script: "./api.js",
      instances: 4,
      exec_mode: "cluster",
      increment_var: "PORT",
      env: {
        PORT: 3000,
      },
    },
  ],
};

This produces: instance 0 gets PORT=3000, instance 1 gets PORT=3001, instance 2 gets PORT=3002, instance 3 gets PORT=3003.

instance_var: customize NODE_APP_INSTANCE

PM2 sets NODE_APP_INSTANCE for each cluster instance (0, 1, 2, …). This conflicts with the node-config library, which uses the same variable for its own purposes. Rename it:

instance_var: "INSTANCE_ID",

Now each instance gets INSTANCE_ID=0, INSTANCE_ID=1, etc. instead of NODE_APP_INSTANCE.

append_env_to_name: multi-environment on one server

If you want to run the same application in development and production on a single machine:

module.exports = {
  apps: [
    {
      name: "my-app",
      script: "./app.js",
      append_env_to_name: true,
      env: { NODE_ENV: "development" },
      env_production: { NODE_ENV: "production" },
    },
  ],
};

With pm2 start ecosystem.config.js --env production, PM2 names the process my-app-production. With no flag, it’s my-app-development. Both can run simultaneously.

Listing and inspecting environment variables in PM2

To see all environment variables for a running process:

# By process ID
pm2 env 0

# By process name
pm2 env my-app

This shows every environment variable the process can see, both the ones you set and all the inherited system variables.

For JSON output (useful for scripting):

pm2 jlist | jq '.[0].pm2_env'

For a formatted view of all processes:

pm2 prettylist

Security best practices for PM2 environment variables

Never hardcode secrets in ecosystem files

Your ecosystem.config.js should be in version control. That means it should never contain real passwords, API keys, or tokens. Instead, inject them at deploy time:

Option 1: Wrapper script that sources a .env file

#!/bin/bash
# start-app.sh
set -a
source /etc/my-app/secrets.env
set +a
pm2 start ecosystem.config.js --env production

Option 2: Systemd environment file

If PM2 is managed by systemd (via pm2 startup), you can set variables in /etc/default/my-app and reference them in the unit file.

Option 3: Secrets manager

For teams and more complex setups, tools like Infisical, Doppler, or HashiCorp Vault can inject secrets at deploy time. For simple solo setups, a .env file with restricted permissions (chmod 600) sourced by a wrapper script is usually enough.

For readers managing secrets in containerized environments, see Docker Compose secrets management for a comparison of approaches.

Using filter_env to limit exposure

If your server runs multiple PM2 applications, filter_env prevents one app from seeing another app’s variables. Prefix-based filtering is the most practical:

filter_env: ["MYAPP_"],

Now only variables starting with MYAPP_ reach your process. Everything else is stripped.

Broader server security

Environment variables are only one part of the picture. If you haven’t already, review securing your SSH server in Linux. If someone gets shell access, all your env vars are exposed regardless of how well you manage them in PM2.

Common PM2 environment variable pitfalls (and how to avoid them)

Conclusion

PM2 environment variables come down to a few core rules:

1. Use ecosystem files for production. They’re explicit, version-controllable, and PM2 re-reads them on restart.
2. Use --update-env when changing CLI-set variables. Without it, pm2 restart is conservative and won’t pick up changes.
3. Delete and re-start for NODE_ENV changes. --update-env doesn’t work for variables read at startup.
4. Use filter_env to limit exposure. Don’t let your app inherit the entire server environment.
5. Test with pm2 env <id>. Always verify what your process actually sees.

For the full process management picture, see the complete guide to managing applications with PM2 and choosing between fork and cluster mode. And if your Node.js dependencies are behind, keeping your Node.js environment up to date is worth the effort. PM2 7.x requires Node.js 18+.
